Type 21H Decorative Radiator 588x600 White

Name: Type 21H Decorative Radiator 588x600 White
SKU: 221H05880600B1PS
Price: 13478.40 TRY
Availability: InStock

Product Code : 221H05880600B1PS

Guarantee : 10 Year

TAXES Included

Price

26,956.80 TL

Discounted Price

13,478.40 TL

10 Years
Warranty

2000€ +
Free Shipping

{"vat":20,"m_o_p":0,"variant_ids":{"69_0":"4808","68_0":"4939","67_0":"5070","66_0":"5201","65_0":"5361","64_0":"5394","63_0":"5427","62_0":"5499","61_0":"5475"},"variant_prices":{"69_0":11232,"68_0":12032,"67_0":12032,"66_0":12032,"65_0":12032,"64_0":12032,"63_0":12032,"62_0":12032,"61_0":12032},"variant_price_raws":{"69_0":11232,"68_0":12032,"67_0":12032,"66_0":12032,"65_0":12032,"64_0":12032,"63_0":12032,"62_0":12032,"61_0":12032},"buying_prices":{"69_0":"0","68_0":"0","67_0":"0","66_0":"0","65_0":"0","64_0":"0","63_0":"0","62_0":"0","61_0":"0"},"not_discounted_prices":{"69_0":"22464","68_0":"24064","67_0":"24064","66_0":"24064","65_0":"24064","64_0":"24064","63_0":"24064","62_0":"24064","61_0":"24064"},"variant_supplier_codes":{"69_0":"221H05880600B1PS","68_0":"221H05880600B1PM1","67_0":"221H05880600B1PM3","66_0":"221H05880600B1PM2","65_0":"221H05880600B1PY0","64_0":"221H05880600B1PC1","63_0":"221H05880600B1PC2","62_0":"221H05880600B1PL4","61_0":"221H05880600B1PR4"},"active_ids":{"one_69":["0"],"two_0":["69","68","67","66","65","64","63","62","61"],"one_68":["0"],"one_67":["0"],"one_66":["0"],"one_65":["0"],"one_64":["0"],"one_63":["0"],"one_62":["0"],"one_61":["0"]},"variant_informations":{"69_0":{"additional_information":""},"68_0":{"additional_information":""},"67_0":{"additional_information":""},"66_0":{"additional_information":""},"65_0":{"additional_information":""},"64_0":{"additional_information":""},"63_0":{"additional_information":""},"62_0":{"additional_information":""},"61_0":{"additional_information":""}},"variant_stocks":{"69_0":"98","68_0":"100","67_0":"100","66_0":"99","65_0":"100","64_0":"100","63_0":"100","62_0":"97","61_0":"100"}}

Options

Standard Entry

Bottom Middle 50mm

Bottom Left 50mm

Bottom Right 50mm

Side-Bottom Right Bottom Left

Cross-Left Bottom Top Right

Cross-Left Top-Right Bottom

Side-55cm Entry Left

Side-55cm Entry Right

Choose Quantity

Add to Cart

Planned Delivery

12.08.2024 (21 Days)

Add Comment Price Allert Add to Favorites

Features
Downloads
Payment Options
Comments (0)

TECHNICAL INFORMATION
• Model = 21H

• Material =Steel

• Height=588 mm

• Width=600 mm

• Color/Coating=Bright White RAL9016

• Number of Sections=8 Pieces

• Total Number of Profiles (Front + Back)=8+8 Pieces

• Profile Dimension=70x11 mm

• Collector Dimension=30x60 mm

• Maximum Working Pressure=4,5 bar

• Radiator Depth=80 mm

• Wall to Center of Inlet=75 mm

• Wall Projection Distance=115 mm

• Radiator Thread Dimension=1/2"

• Water Volume=6,8 lt

• Weight=20,5 kg

• Boxed Weight=21,86 kg

• Box Size=64x66x11,6 cm

TAPPING OPTIONS

• Standard Entry=550 mm

• Bottom Middle Entrance=50mm

• Bottom Right Entrance=50mm

• Bottom Left Entrance=50mm

• Sides / Bottom Right-Left=690mm

• Cross Up-Right / Down-Left=690mm

• Cross Up-Left / Down-Right=690mm

• Side - Right=550mm

• Side - Left=550mm

Heat Output

Kcal / h

• Heat Output 75/65-20°?t=50°C = 685 Kcal/h

• Heat Output 90/70-20° ?t=60°C=864Kcal/h

• Heat Output 55/45-20° ?t=30°C=351Kcal/h

Watts

• Heat Output 75/65-20°?t=50°C=796 Watt

• Heat Output 90/70-20°?t=60°C=1003 Watt

• Heat Output 55/45-20°?t=30°C=408 Watt

Btu

• Heat Output 75/65-20°?t=50°C=2716 Btu

• Heat Output 90/70-20°?t=60°C=3423 Btu

• Heat Output 55/45-20°?t=30°C=1391 Btu

Warranty

:

10 Years

Delivery Information

:

21 Day
