COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 4K
• Material = Steel
• Height = 300 mm
• Width = 1636 mm
• Color = Matt Black
• Number of Columns = 4
• Number of Sections = 35 Pieces
• Legs Needed If Free Standing = 3 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 108 mm
• Wall Projection Distance = 182 mm
• Section Width = 46 mm
• Radiator Depth = 148 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 28 lt
• Radiator Weight = 31,5 kgTAPPING OPTIONS
• Standard Entry1 = 230 mm
• Standard Entry Cross = 1726 mm
• Sides / Bottom Right-Left = 1726 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 1274 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 1606 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 653 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 1481 Watt
• Heat Output 90/70-20° ∆t=60°C = 1867 Watt
• Heat Output 55/45-20° ∆t=30°C = 759 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 5054 Btu
• Heat Output 90/70-20° ∆t=60°C = 6369 Btu
• Heat Output 55/45-20° ∆t=30°C = 2588 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
